YK 110 Power Switch Controller ( DJS-99 ) - 10 Channel Power Controller 10 Power Switch Controll

2.10 Power switch with Light indicator

3.With Holes on sides for mounting purposes

4.Size: 48.5 x 9.5 x 5 cm

5.Weight: 1.6 kg

6.Protects gadgets/appliances

7.Ideal for mobile DJs Clubs, Bands, home or office

Product details of Trident YK-110 10 Channel Power Controller 10 Power Switches

10 lighted switches on front panel

15amp. resettable circuit breaker on front panel

Eight grounded AC sockets on rear of the unit

Maximum load: 15 amps or 1800 watts

1 rack mount space

Professional 8+2 power sequencer, 8 controllable power supply channels + 2 auxiliary power supply channels, built-in air switch, support independent on/off channels, display current voltage, effectively protect equipment, one-key boot sequence 1~8 channels to turn on the power , Shutdown sequence 8~1 channel power off, power supply AC220V 50Hz, rated power: 6600W, single channel maximum output current 30A, support various power plugs

Power sequencer

Loading per channel: 220v/30A,6600W/channel

Input voltage: AC220V/50Hz

Rated power: 5200W, total capacity 30A

Output power: The maximum output current of each socket is 30A

8 channels at the rear

Universal connector

Sequency time per step: 1 second

There are independent switches, AC voltage indicator lights, multimedia power sockets

Input method: 3*2.5 square plug AC power cord

Output mode: 8-way power output, standard universal three-pin socket

Function: When turned on, start one by one from front to back, and close one by one from back to front

Off phase, the action time between each channel is 1 second

Switch/Indication: Panel Power Indicator

Indication after each channel is powered on

Box size: 55x26x9cm

Product size: 483x438x44mm
