Hot Gigabit Switch Hub 10/100Mbps Base 8 Ports High Performance Ethernet Network Switch Support Full Half Duplex EU/US Plug

DefinitionPL-GS3008DR-A1 8 port gigabit switch 10/100 / 1000mbps ethernet network lan hub

Simple Features1 8 port ethernet network gigabit switch 2 Desktop 3 Plug n Play 4 Metal case 5 5-12V1A power adapter

ApplicationsThe 8 port ethernet network gigabit switch is widely used in companies, hotels, school, office, small Local area network and other places

FeaturesComplies with IEEE 802.3, IEEE 802.3u and IEEE 802.3ab standards 8port 10/100 / 1000Mbps Auto-Negotiation RJ-45 ports, supporting Auto-MDI / MDIX Supports 8K-entry MAC address table with 4-way hash algorithm Support IEEE 802.3x flow control for full duplex mode and backpressure for half duplex mode on all port Non-blocking switching architecture that forward and filter packets at wire-speed for maximum throughput Support MAC address auto-learning and auto-aging LED indicators for monitoring power, link and activity desktop metal case External supply power DC5-12v 1a 8port 10/100 / 1000M Gigabit switch Specifications Standards IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet ANSI / IEEE Std 802.3 Nway Auto-Negotiation IEEE 802.3x flow control protocol CSMA / CD Transmission Rate Ethernet 10 Mbps (half duplex), 20 Mbps (full duplex); 10BASE-T: 14,880 pps / port Fast Ethernet 100Mbps (half duplex), 200Mbps (full duplex); 100BASE-TX: 148800pps / port Gigabit Ethernet 2000Mbps (full duplex), 1000BASE-T: 1488000pps / port Topology Star Network Medium 10Base-T: Cat 3 or above Cat.3 UTP (≤100m) 100Base-TX: Cat 5 UTP (≤100m) 1000Base-T: Cat 6 or above Cat.5 UTP (≤100m) Number of Ports 8 port 10/100 / 1000M RJ45 ports UPLINK Any port (support Auto-MDI / MDIX function) Transmits Method Store-and-Forward Temperature Operating Temperature 0 C ~ 40 C (32 F ~ 104 F) Storage Temperature -40 C ~ 70 C (-40 F ~ 158 F) Humidity Operating Humidity 10% ~ 90% non-condensing Storage humidity 5% ~ 95% non-condensing Switch capacity16G

LED Indications
