1602 16x2 I2C LCD Module Display for Arduino Raspberry Pi 80mm Blue Yellow Green Backlight Adjusts Contrast Easily

*LCD screen can display 2 lines x 16 characters, operating voltage: 5V; with a potentiometer to adjust backlight and contrast.

*Fewer I/O ports are occupied, only four- VCC, GND, SDA(serial data line), SCL(serial clock line), cabling: GND—GND; VCC- VCC; SDA-A4; SCL—A5, LCD display module in yellow-green color.

*Supports IIC protocol. The I2C LCD1602 library is included so you can access it directly to adjust backlight and contrast.

*Application The LCD module is used to display characters, letters, numbers, real-time clock and temperature.

*1602 LCD display with I2C series interface is compatible for Arduino and for Raspberry Pi, Display function: LCD display with I2C series interface can be used to display real-time clock, temperature, humidity, etc.

Specification:

Part Name: 1602 LCD screen module

Color: As shown

Size: 80*36mm/3.14*1.41in

Material: plastic

With IIC: optional

Display: 2 lines x 16 characters

Backlight: blue screen, yellow-green screen

Four Pin Definition: GND, VCC, SDA, SCL

Operating voltage: 5V

Contrast adjustment: potentiometer

Backlight adjustment: for Jumper

Wiring:

GND—GND; VCC- VCC; SDA-A4; SCL—A5

Package Contents:

1*1602 LCD screen module

Note:

1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.
