β±35.00
PWM DC Motor Speed Regulator 5A 3V-35V Speed Control Switch Function | PWM 1803BK Motor Speed Controller | DC Motor Speed Controller PWM Regulator 6V-28V Switch Module | ZKMG DC5-30V 5A with LCD | 6V-60V 30A PWM LED Digital
Sold by Makerlab Electronics
5(30)
317 sold
Select options
Select
Shipping
From β±36.00
Est. delivery by Apr 19 - Apr 22
Specifications
Customer reviews (30)
D**s T**
Item: Red 5A 3V-35V
Ok maganda, sana lng d po cra para magamit ko
August 26, 2024
d**s
Item: Red 5A 3V-35V
Ok nmn xa maganda ang pagkabalot ,testing palang umusok na ,sunog agad Tama nmn ang connection.,
May 21, 2024
T**3
Item: Red 5A 3V-35V
InstallationοΌGood product thank
January 11, 2025
π**π
Item: Red 5A 3V-35V
Okay naman yung materyales maganda sulit naman
July 19, 2024
T**3
Item: Red 5A 3V-35V
Good product thank you po
3d ago
r**a
Item: Red 5A 3V-35V
Quality of workοΌ100%
InstallationοΌ100%
April 26, 2024
N**E
Item: Red 5A 3V-35V
Salamat po saler natangap kuna po order
September 10, 2024
b**p
Item: Red 5A 3V-35V
Well packed the item in good condition.
July 16, 2024
S**y
Item: Red 5A 3V-35V
It is working. Hope it last for long.
May 25, 2024
d**8
Item: BLACK 3A 6V-28V
Sana tumagal
May 1, 2024
π**g S**π
Item: Red 5A 3V-35V
Legit and working naman.
August 17, 2024
r**6
Item: Red 5A 3V-35V
Thank you God bless ππ
April 16, 2024
g**m
Item: Red 5A 3V-35V
Working perfectly
March 11, 2025
m**s
Item: Red 5A 3V-35V
Goods na goods
July 12, 2024
M**o c**h
Item: Red 5A 3V-35V
Good quality
June 5, 2024
u**7
Item: Red 5A 3V-35V
Good items
May 23, 2024
J**n D**r C**z
Item: Red 5A 3V-35V
Excellent
June 3, 2024
p**o
Item: Green 2A 1.8V-15V
Quality
1w ago
B**n
Item: Red 5A 3V-35V
Maganda
November 5, 2024
A**t
Item: Green 2A 1.8V-15V
thanks
May 30, 2024
Makerlab Electronics
973 items
Shop performance
Better than 94% of other shops
Ships within 2 days
89%
Responds within 24 hours
95%
About this product
Warranty TypeSupplier Warranty
Product description
RED PWM
Product Parameters:
β’Working voltage: DC 4.5β―V β 35β―V
β’Output current: 0β―ββ―5β―A
β’3Output power: 90β―W (maximum)
β’Quiescent current: 7β―ΞΌA (standby state)
β’PWM duty cycle: 1β―%β―ββ―100β―%
β’PWM frequency: 20β―kHz
β’Size: lengthβ―30β―mm Γ widthβ―26β―mm (without handle) Γ heightβ―14β―mm
β’Weight: 0.013β―kg
Precautions:
β’DC motor governor input is DC, not directly connected to AC (for example: household 220β―Vβ―AC), otherwise it will burn out!
β’Do not reverse the positive and negative terminals of the DC power supply, otherwise the governor may be damaged.
β’The motor can be positive or negative. When the running direction is inconsistent with the expectation, the direction can be changed by adjusting the line sequence.
β’Adjusting the potentiometer knob can change the governor output duty cycle and the motor speed changes.
GREEN PWM
DC motor speed controller can easily provide 2β―A continuous current for a DC motor or other DC loads. With self-recovery fuse 2β―A and short LED light. PWM DC motor speed controller with switching function.
Technical Parameters
β’Input voltage range: DCβ―2.2β―ββ―12β―V
β’Output voltage: 1.8β―ββ―12β―V (adjustable according to the power supply voltage)
β’Output current: <β―2β―A
β’Connect the DC motor debugger to a direct power source. Do not directly connect to household 220β―Vβ―AC power supply, otherwise you will be responsible for the damage!
β’The current of the governor is 2β―A. If the connection current is greater than 0.5β―A (for example, a 775 motor, baby-car motor, etc.), it cannot be driven, so please do not buy the wrong motor.
β’It is not recommended to use a power supply exceeding 12β―V (e.g., a 12β―V lead-acid battery), otherwise the governor may be damaged.
Size:32β―Γβ―32β―Γβ―20β―mm (1.25β―Γβ―1.25β―Γβ―0.78β―inches)
BLACK PWM
Description
:The PWM DC Motor Speed Controller Speed Switch Module 6β―V / 12β―V / 24β―V / 28β―V 3β―A, which can regulate and boost voltage as it should.
There is a reversing three-position rocker switch on the controller board. Positions are CW β OFF β CCW. While the motor is on, you can turn the rotary knob to adjust the speed, in whichever direction the motor is going.
Specification
β’Function: Speed Control
β’Input voltage range: DCβ―6β―ββ―28β―V
β’Current range: Within 3β―A (maximum)
β’Maximum output power: 80β―W
β’Switch function: None
β’Duty cycle range: 0β―ββ―100β―%
β’Size (Lβ―Γβ―Wβ―Γβ―H): Approx. 50β―Γβ―32β―Γβ―15β―mm (1.3β―Γβ―2β―Γβ―0.4β―inches)
β’Net Weight: 1.13β―ounces
Features
β’Small, compact, snugly built, with a wide range of DC application
β’Very smooth speed adjustment tool (PWM control) for LED lights and motors
β’Easy installation with terminals is a nice touch
β’The power/direction switch makes it one of the best choices for driving small to medium sized DC motors
β’Potentiometer with switch function. The silver turning knob smoothly clicks at off position, and rotation allows very precise movement
PWM w/ LCD (General Features)
1.1 Equipped with startβstop button, and can be external switch control, to meet various customer control requirements.1.2 Motor soft start function. When starting the motor, the current increases slowly and there is no shock current, which can effectively protect the motor and prolong its service life.1.3 Duty cycle, duty cycle upper and lower limits, and working frequency can be setβthis helps users operate and use their motors according to their working characteristics.1.4 Digital encoder knob adjusts motor speed, which is more accurate and consistent than an ordinary potentiometer.1.5 Comes with a standard 5135 instrument shell, convenient for customer installation.
Specifications
β’Working voltage: DCβ―5β―V β 30β―V, input anti-reverse connection protection
β’Rated current: 5β―A (maximum current 15β―A)
β’Maximum power: 150β―W
β’Working frequency: 1β―kHz β 99β―kHz (adjustable, 1β―kHz step), default frequency of 20β―kHz, accuracy about 1β―%
β’Duty cycle: 0β―ββ―100β―%, 1β―% step
β’Product size: 79β―Γβ―43β―Γβ―26β―mm
Operation Instructions
β’In the default interface (the duty cycle is displayed by default)
β’Short press β switch motor start and stop
β’Long press β enter the setting interface
β’Counterclockwise rotation β the duty ratio decreases
β’Clockwise rotation β the duty ratio increases
PWM LED DIGITAL 30A 6β―V β 60β―V
Specifications
β’Input voltage: DCβ―6β―ββ―60β―V
β’Output current: 0β―ββ―30β―A
β’Continuous current: within 20β―A
β’Speed control mode: jog
β’Support motor: DC brushed
β’Speed range: 0β―ββ―100β―%
β’Control frequency: 21β―kHz
β’Wiring type: fence terminal block
β’Size: 96β―Γβ―34β―Γβ―61β―mm
WARNING:
DO NOT REVERSE POSITIVE AND NEGATIVE POWER LOADS. THIS WILL DAMAGE THE CONTROLLER.
βAdjusting the potentiometer knob can change the governor output duty cycle and the motor speed changes.β
